MINI EXCAVATOR

HT15Pro Mini Excavator for Confined-Space Work

The HT15Pro is a 1.5-ton mini excavator engineered for confined-space work. With an overall width of just 930 mm and a tail turning radius of 800 mm, it navigates narrow passages and tight courtyards. It comes standard with hydraulic pilot controls for smooth operation and features a 360° rotating upper structure and an optional side-swing boom.

Brand:
HIGHTOP
Spu:
HT15Pro

The HT15pro 1.5ton crawler mini excavator comes standard with hydraulic pilot operation, 360 degree rotation of the body and side-to-side swing of the boom, allowing it to work in spaces up to 1 meter wide, making it suitable for operation in confined spaces.

  • Overview
  • Parameter
  • Details
  • FAQ
  • Applications
  • Related Products

HT15Pro 1.5 Ton Mini Excavator: Pilot Control and 930mm Width

The HT15Pro is a compact 1.5-ton mini excavator built for projects where access is limited but digging performance still matters. With an overall width of just 930 mm and a tail swing radius of 800 mm, it easily navigates narrow garden gates and confined working areas without the rear body hitting obstacles.

Standard Hydraulic Pilot Controls

Unlike economy models that use mechanical levers, the HT15Pro comes standard with hydraulic pilot controls on both joysticks. This provides smoother, faster, and more precise movement coordination, drastically reducing operator fatigue during long shifts.

360° Rotation and Swing Boom

The upper structure rotates 360°, allowing the operator to dig, load, and reposition material without moving the chassis. For working parallel to walls, an optional side-swing boom is available.

Durable Design and Flexible Options

The machine features a reinforced molded canopy with 38mm steel tubes for safety, and stamped exterior covers for a precise fit. It is equipped with a reliable KOOP or Briggs & Stratton engine. For extreme narrow access, an optional retractable track system is available. All travel and swing motors include dedicated oil drain pipes to simplify maintenance.

HT15PRO Mini Excavator – Technical Specifications

Parameter Specification
Machine Dimensions (mm)
Transport Length (A) 2300 mm
Overall Width (B) 930 mm
Upper Width (D) 990 mm
Overall Height (C) 2270 mm
Standard Track Shoe Width (F) 180 mm
Track Gauge (E) 750 mm
Shovel Height Above Ground (G) 110 mm
Depth of Excavation of Bulldozer (H) 200 mm
Tail Turning Radius (I) 800 mm
Track Ground Length (J) 890 mm
Track Length (K) 1235 mm
Working Range (mm)
Max. Digging Height (a) 2690 mm
Max. Dumping Height (b) 1825 mm
Max. Digging Depth (c) 1710 mm
Max. Digging Reach (d) 2920 mm
Min. Swing Radius (e) 1500 mm
Max. Height at Min. Swing Radius (f) 2110 mm
Performance
Weight 1500 kg
Bucket Capacity 0.02 m³
Working Device Form Backhoe
Gradeability 30°
Main Components
Engine Koop / Briggs & Stratton
Main Valve Tengfei

HT15Pro 1.5ton Mini ExcavatorHT15Pro 1.5ton Mini ExcavatorHT15Pro 1.5ton Mini ExcavatorHT15Pro 1.5ton Mini ExcavatorHT15Pro 1.5ton Mini ExcavatorHT15Pro 1.5ton Mini ExcavatorHT15Pro 1.5ton Mini ExcavatorHT15Pro 1.5ton Mini Excavator

Frequently Asked Questions (FAQ)

What are the benefits of hydraulic pilot controls?+
Hydraulic pilot controls use joysticks to manage the main valves, providing much smoother and more precise digging movements compared to mechanical levers. It also significantly reduces operator fatigue.
Will the 930mm width fit through a narrow gate?+
Yes. The standard overall width is 930 mm, which fits most residential gates. For even tighter spaces, we offer an optional retractable track system to further narrow the machine.
What is the actual operating weight of the HT15Pro?+
The working weight is 1,000 kg. We can provide pre-shipment scale tickets and weighing videos upon request to verify the exact weight.
Can I get a closed cabin or swing boom for this machine?+
Yes. Both a closed cabin (for weather protection) and a side-swing boom (for digging parallel to walls) are available as optional configurations. Please specify your requirements when requesting a quote.

HT15Pro Mini Excavator Applications

The HT15Pro 1.5 ton mini excavator is designed for contractors, landscapers and small construction businesses that need a compact machine with flexible operation capability.

  • Landscaping Projects: Suitable for garden construction, soil preparation, tree planting and landscape maintenance.
  • Small Construction Work: Useful for excavation, trenching, foundation preparation and property improvement projects.
  • Agricultural Applications: Suitable for farm maintenance, land improvement and small excavation tasks.
  • Utility Installation: Can be used for drainage, pipeline installation and other compact excavation work.
  • Rental Equipment: A practical option for rental companies serving customers with different small-scale excavation needs.
