EN
1-Japan Kubota D722 engine ,10.2KW/2500rpm, Euro 5,EPA4
2-China brand pump
3-China brand valves
4-China brand slewing motor
5-China brand driving motor
6-closed cabin/open canopy
7-Hydraulic pilot servo operation system
8-Steel track:200mm
9-With hydraulic hammer pipeline system
10-Bucket capacity: 0.03m³
11-With Improved control system
12-with high-low speed
13-with side boom14-Tailless design
HIGHTOP18 1800kg Mini Hydraulic Excavator – Diesel-Powered Micro Digger! Compact Maneuverability for Urban Jobs, Farms & Tight-Space Projects
- Overview
- Related Products
Product Description
Tackle confined challenges with the HIGHTOP18 1800kg Mini Hydraulic Excavator—a diesel-fueled micro digger engineered for ultra-compact power! Perfect for urban construction, farming, or backyard projects, this agile machine blends heavy-duty hydraulic force with nimble 360° swivel operation, slicing through soil, gravel, or roots in tight alleys, gardens, or narrow construction zones. Its adjustable undercarriage and zero-tail-swing design pivot flawlessly around obstacles, while quick-coupler hydraulics swap buckets, breakers, or augers in seconds. Fuel-efficient diesel engine cuts costs, and low-noise operation keeps neighbors and livestock calm. Built for daily durability yet gentle enough for property upgrades—ideal for contractors, hobby farmers, or DIY trailblazers.
Easy to operate
Controls are easy to use and the intuitive Next Generation LCD monitor provides easy to read machine information.
Big Performance in a compact design
Strong lift and dig performance helps you get the job done faster. The retractable undercarriage lets you access and work in the tightest areas. Dig-to-blade and dozer float features allow for easy clean up.
Maintenance and shutdown issues
Easy to operate
Controls are easy to use and the intuitive Next Generation LCD monitor provides easy to read machine information.
Big Performance in a compact design
Strong lift and dig performance helps you get the job done faster. The retractable undercarriage lets you access and work in the tightest areas. Dig-to-blade and dozer float features allow for easy clean up.
Maintenance and shutdown issues
Our company provides 1 years after-sales service and efficient problem-solving speed for excavator
problems, reduces downtime and keep your excavator running normally.
problems, reduces downtime and keep your excavator running normally.
Delivery time
We have sufficient inventory of spare parts and accessories, coupled with efficient logistics and distribution channels, to ensure timely delivery when you need them.
Specification
Model |
HT18 |
|
Performance Parameter |
||
Operating weight（KG) |
1800KG |
|
bucket capacity |
0.03 |
|
Bucket width |
40cm |
|
rated power |
10.2KW/2500RPM |
|
Swing speed |
12RMP |
|
Gradeability |
30 degrees |
|
Engine |
KUBOTA D722 |
|
Main valve |
Beifang |
|
Main pump |
Double pump |
|
Fuel tank capacity |
7.5L |
|
Hydraulic oil tank capacity |
21L |
|
Working Range |
||
Max.digging height a |
2580 mm |
|
Max. uploading height b |
1637 mm |
|
Max.digging depth c |
2060 mm |
|
Max. digging distance d |
3160 mm |
|
Mini. radius of gyration e |
1711 mm |
|
Max.height at minimum radius of gyration f |
2048 mm |
|
Overall Dimensions |
||
Overall length |
4325 mm |
|
Transport length A |
1655 mm |
|
Overall width B |
1100 mm |
|
Upper width D |
990 mm |
|
Total height C |
2272 mm |
|
Width of track shoe F |
180 mm |
|
Gauge G |
920 mm |
|
Minimum ground clearance H |
119 mm |
|
Tail turning radius I |
790 mm |
|
Track ground length J |
1050 mm |
|
Track length K |
1545 mm |
|
Swing Boom (Lift/Right) |
60 degrees |
|
